Spicer Front Steering Knuckle Kingpin Master Rebuild Kit for Chevy, GM & Ford (Dana 60, Single Side)

Eliminate violent front-end death wobble, correct erratic steering wander, and completely rebuild your heavy-duty steering knuckle pivots with this genuine Spicer Kingpin Master Rebuild Kit. Specifically engineered to overhaul iconic Kingpin Dana 60 solid front axles, this comprehensive single-side package replaces all worn-out upper and lower steering knuckle components.

On classic 1-ton 4x4 platforms, the steering knuckles rotate on a heavy-duty mechanical interface consisting of a threaded upper steel kingpin and a lower tapered roller bearing. Over high mileage, intensive commercial fleet use, or rugged off-road trail abuse, the upper nylon cone bushings distort or split, the massive tension springs fatigue, and the lower bearings fall victim to moisture contamination and pitting. When these components develop excess play, it introduces dangerous lateral slop into the steering knuckle—resulting in severe front-end tracking instability, accelerated tire wear, and an unresponsive steering wheel feel.

This original equipment manufacturer (OEM) master service package supplies everything needed to properly refresh one complete front steering knuckle station. Sourcing genuine Spicer components guarantees exact original equipment dimensional specifications, correct steel tempering for high-torque loads, and high-density polymer formulas engineered to handle extreme vertical chassis weight without premature failure.

Kit Contents (Services One Steering Knuckle Side):

• (1) Premium Threaded Steel Upper Kingpin (Part # 41884)

• (1) High-Density Upper Tapered Nylon Cone Bushing (Part # 41886)

• (1) Heavy-Duty Upper Kingpin Compression Spring (Part # 41877)

• (1) Lower Kingpin Tapered Roller Bearing Assembly (Part # 41864 / 11590)

• (1) Lower Kingpin Bearing Seal & Grease Retainer

• (1) Premium Upper Kingpin Gasket & Seal Pack

Kit Highlights:

• Complete Knuckle Overhaul: Combines the primary upper kingpin components and the lower bearing assembly to fully rebuild one front steering station.

• Genuine Spicer OEM Quality: Manufactured by the industry-leading original equipment supplier to guarantee perfect structural compliance and factory-spec load ratings.

• Cures Death Wobble & Play: Re-establishes zero-tolerance alignment inside the knuckle assembly, stopping dangerous front-end vibrations and restoring tight handling.

• Heavy-Duty Fatigue Life: Built with premium-tempered steel and high-cleanliness industrial materials to resist trail impacts, steering friction, and moisture infiltration.

Vehicle & Axle Fitment:

• Axle Profiles: Open-Knuckle Solid/Monobeam Front Dana 60 Kingpin Axles (Does not fit later ball-joint style Dana 60 axles).

• Chevy / GMC Trucks: 1977–1991 Chevy/GMC K30, V30, and K3500 1-ton trucks (including military CUCV M1008 and M1028 rigs).

• Ford Trucks: 1978–1979 F-250, and 1979–1991 F-350 1-ton 4x4 heavy-duty trucks.

• Dodge Trucks: 1975–1993 W250 and W350 heavy-duty 4WD trucks.

• Position: Front Steering Knuckle Pivot (Fits Left or Right Side — 2 Kits Required per Vehicle)
